• MaxComm 5G Outdoor CPE OWR-203

MaxComm 5G Outdoor CPE OWR-203

modelo : OWR-203

Air Interface Technical Standard 5G NR Sub-6GHz,mmWave,TDD-LTE,FDD-LTE
802.11 a/b/g/n/ac/ax
Frequency North America:
5G NR : N2/N5/N7/N12/N13/N14/N25/N26/N30/N41/N48/N66/N71/N77/N78
5G mmWave:
N258/N260/N261 LTE:
B2/B4/B5/B7/B12/B13/B14/B25/B26/B29/B30/B66/B71/ B41/B46/B48 WCDMA:
B2/B4/B5
Japan5G NR :
N3/N28/N77/N78/N79
5G mmWave:
N257 LTE:
B1/B3/B8/B11/B18/B19/B21/B26/B28/B41/B42 WCDMA:
B1/B5/B8
South Korea: 5G NR :
N78/N1/N3/N8
5G mmWave: N257
LTE: B1/B3/B5/B7/B8
WCDMA:
B1
WIFI Support WiFi6 2.4GHz&5.8GHz20,40,80,160Mhz Channels WIFI 4*4 MIMO802.11 a/b/g/n/ac/ax, DBDC
Performance Maximum Data Throughput 5G NR mmWave
- MIMO 2*2, 64QAM
- Downlink up to 6.1Gbps(due to the limit of LAN and WLAN)
- Uplink up to 2.98Gbps
5G NR Sub-6GHz:
- MIMO 4*4, 256QAM
- Downlink up to 3.3Gbps
- Uplink up to 300Mbps
LTE Cat20:
- MIMO 4*4, 256QAM
- Downlink up to 2.0Gbps
- Uplink up to 150Mbps
MIMO Support DL 4x4 MIMO
Modem Chipset Qualcomm SDx55
Receive Diversity Support Receive Diversity
AP Chipset Qualcomm  IPQ8072A
SENSOR 6 Axis, Acceleration+Gyroscope
GNSS Support
USIM/SIM 2*4FF SIM (nano card)
Hardware Memory Modem:
4Gb NAND + 4Gb LPDDR4 AP:
Default 64Mb NOR+EMMC 128Gb+16Gb RAM
Power consumption <60W
Ethernet C
Power POE(802.3AF/AT/BT)
LED LED*4:
Power Indication LED,
5G/4G network Indication LED, Ethernet  Indication LED,
WiFi Indication LED
USB USB 2.0 Type-C, default connect to IPQ board
Antenna Internal Antenna: LTE*5,  5G NR*4, WIFI*4, QTM527*4, GNSS*1
Buttons RESET
ESD ESD Protection circuit8kV contact / 10kV air discharge.
Software SW Update Local Update
WIFI Mode AP mode
WIFI Security OPEN & WPA2-PSK & WPA-PSK/WPA2-PSK & WPA3
IPv4 Support IPv4
IPv6 Support IPv6
VPN Pass Through PP2P/L2TP/IPSec
UI WebUI
Firewall Mac/IP address filter, Port forwarding, WiFi Black/Whilte list
Data Statistics Support
Automatic APN Matching According to USIM Support
SNTP Support
DMZ Support
HTTP Support
HTTPS Support
TR069 Support
Certification Certification It can support KC/TTA/SK and can be customized base on  requirement.
Environment Waterproof level IP67
Lightning Protection provide outdoor ground terminal to lower the ground potential. When lightning does hit,
it can discharge to earth ground.
Operating Temperature Full compliance: -20°C to 60°C;
Operational but with certain degradations: -30°C to -20°C; 60°C - 70°C.
Storage Temperature -40°C to +80°C
Humidity 5%~ 95%
